Yagi Antennas

Yagi Antennas 1005

The YMA Series of antennas are ideal for use in surveillance and UAV applications where rugged design and moderate-gain is required for medium-range operations. These linear polarized directional antennas are available in frequency bands from 1.7 through 5.0 GHz. Each YMA Series antenna features an SMA connector and is enclosed in an ABS radome to provide reliable service in adverse environments. Models range in gain from 10 dBi through 16 dBi to meet a variety of applications. YMA Series antennas are compact, lightweight, and suitable for tactical or long-term deployment missions.

Download the Yagi Antennas data sheet - PDF Version

Technical Specifications

Model
Type
Fo GHz
Gain
Polarity
Connector
HPBW
YMA-L10Bare Wire Yagi1.71 - 1.85 GHz10 dBiLinearSMAH-60º, E-40°
YMA-L10RYagi + Radome1.71 - 1.85 GHz10 dBiLinearSMAH-60º, E-40°
YMA-S10Bare Wire Yagi1.99 - 2.11 GHz10 dBiLinearSMAH-60º, E-40°
YMA-L16Bare Wire Yagi1.71 - 1.85 GHz16 dBiLinearSMAH-30º, E-20°
YMA-S16Bare Wire Yagi1.99 - 2.11 GHz16 dBiLinearSMA H-30º, E-20°
YMA-S10Bare Wire YagiS-band10 dBiLinearSMAH-60º, E-40°
YMA-S10RYagi + RadomeS-band10 dBiLinearSMAH-60º, E-40°
YMA-S16Bare Wire YagiS-band16 dBiLinearSMAH-30º, E-20°
YMA-C112RYagi + Radome3.0 - 4.0 GHz12 dBiLinearSMAH-60º, E-40°
YMA-C212RYagi + Radome4.4 -5.0 GHz12 dBi LinearSMAH-60º, E-40°
YMA-C216RYagi + Radome4.4 -5.0 GHz16 dBi LinearSMAH-30º, E-20°

More models are available - call for details.
